10 Kw Offf Grid Solar Panel System
- BI-FACIAL Solar panel
N-type TopCon half cell panels Voltage: 41.97V
Rated power: 590w
connection: 3pcs in series,6strings in parallel"
18PCS
Advantage
23% Transfer Efficiency
25 Years warranty
- Combiner
4T-48V
Multiple PV strings inputs
max circuit voltage: 800V
2PCS
Advantage
Wide Range of DC Input Voltage
Thunder And Lightning Protection
- MPPT charge controller CE,ROHS certificate
48V 100A
2PCS
Advantage
99.9% efficiency
2Years Warranty
- Solar Inverter CE,ROHS certificate
Rated Power:10KW
DC voltage:48V
AC Output :110V/220V
1PCS
Advantage
AC Grid Charger Build In USA IR materials
2Years Warranty
- Powerwall lithium battery CE,ROHS certificate
Capacity: 15KWH power Total: 30KWH
2PCS
Advantage
Germany Technology
Including BMS
10years warranty
20years design lifespan
Lifepo4 Battery
- Bracket
Rooftop / Ground Install
Customized,Including All Parts
1SET
Advantage
10years warranty
- PV Cables/Connetor
1) 6pcs 16mm2*2M battery cable 20M 16mm2 cable
2) 4mm2 PV cable 200M
3) 2P 100A Battery switch and box
4) 6-pole bronze terminal
5) Ground wire
1SET
Advantage
Professional processed battery cable.
10years warranty
